Do Not Re-Mesh - Morphing Shape Optimization in Ansys Mechanical
[av_image src=’https://www.ozeninc.com/wp-content/uploads/2019/05/rbf-1030×500.png’ attachment=’126318′ attachment_size=’full’ align=’center’ styling=” hover=” link=” target=” caption=” font_size=” appearance=” overlay_opacity=’0.4′ overlay_color=’#000000′ overlay_text_color=’#ffffff’ animation=’no-animation’ admin_preview_bg=”][/av_image]
Join the RBF Morph team to learn how best in class mesh morphing can leverage FEM analyses with Ansys Mechanical. The RBF Morph ACT Extension extends the capability of the structural solver keeping the same look and feel as it is perfectly integrated in the UI. The radial basis functions (RBF) mesh morphing technology allows to get a shape parametric FEM model just with a few clicks. Shape optimisation becomes so easy and affordable even for very large meshes. The webinar, after a brief overview, will introduce the technology reviewing a collection of users’ success stories. Among them we will show in detail, with a step by step hands on, how the stress at the root fillet of a turbine blade can be reduced by 22%.
https://catalog.ansys.com/product/5b3bc6857a2f9a5c90d32ea9/rbf-morph-act-exte
