Ansys Motor-CAD
Ansys Motor-CAD is a dedicated electric machine design tool for fast multiphysics simulation across the full torque-speed operating range. Motor-CAD enables design engineers to evaluate motor topologies and concepts across the full operating range, to produce designs that are optimized for performance, efficiency and size. Motor-CAD software’s four integrated modules—EMag, Therm, Lab, Mech—enable multiphysics calculations to be performed quickly and iteratively, so users can get from concept to final design in less time. Motor-CAD’s intuitive, template-based setup simplifies and automates the analysis process while its built-in electromagnetic, thermal and mechanical solvers offer valuable multiphysics insights into a motor design. The simulations can be completed in a matter of seconds thus allowing ample time and scope for extensive design space exploration. Ansys Motor-CAD enables engineers to produce optimized electric motor and generator designs to help meet the size, weight, energy efficiency, cost and other specifications.
For deep analysis and validation of the motor design the Motor-CAD model can be transferred to Ansys Maxwell, Ansys Icepak and Ansys Fluent. Combining these solvers with Motor-CAD delivers high-fidelity, 2D/3D analysis capability enabling users to analyze end-effects, demagnetization, core loss, hysteresis and other advanced electromagnetic phenomena, calculate the thermal envelope for operation and design complete motor cooling systems.
Motor-CAD Capabilities
Calculate torque, power, currents, efficiency, torque ripple, losses (copper, iron and eddy current), flux linkages, inductances and forces.
Optimize an electric machine’s cooling using the analytical lumped parameter thermal modeling technique, to calculate thermal resistances and capacitances.
Rapidly create efficiency and loss maps, plot torque/speed characteristics and analyze an electric machine’s performance throughout drive cycles.
Estimate mechanical strain, stress and displacements induced in a rotor by centrifugal forces to size it for optimal electromagnetic performance.
Transfer a Motor-CAD model to Ansys Maxwell, Ansys Icepak or Ansys Fluent to analyze end-effects, demagnetization, core loss, hysteresis and noise-vibration-harshness.
Options: permanent magnet-based electric machines, asynchronous electric machines with an induced rotor field and synchronous electric machines without permanent magnets.
